Description 231-639/129-000 1-conductor male connector; CAGE CLAMP®; 2.5 mm²; Pin spacing 5.08 mm; 9-pole; Snap-in flange; 2,50 mm²; orange
- Universal connection for all conductor types
- Easy cable pre-assembly and on-unit wiring via vertical and horizontal CAGE CLAMP® actuation
- For wire-to-wire and board-to-wire connections
- Versions available with snap-in mounting feet or flanges for panel or through-panel mounting
- With coding fingers
Main attributes 231-639/129-000 1-conductor male connector; CAGE CLAMP®; 2.5 mm²; Pin spacing 5.08 mm; 9-pole; Snap-in flange; 2,50 mm²; orange
Connection 1
Actuation direction 1
Operation parallel to conductor entry
Actuation direction 2
Operation perpendicular to conductor entry
Actuation type
Operating tool
Conductor entry direction to mating direction
0 °
Connection technology
CAGE CLAMP®
Fine-stranded conductor
0.08 … 2.5 mm² / 28 … 12 AWG
Fine-stranded conductor; with insulated ferrule
0.25 … 1.5 mm²
Fine-stranded conductor; with uninsulated ferrule
0.25 … 2.5 mm²
Pole number
9
Solid conductor
0.08 … 2.5 mm² / 28 … 12 AWG
Strip length
8 … 9 mm
Connection data
Clamping units
9
Number of connection types
1
Number of levels
1
Total number of potentials
9
Environmental requirements
Limit temperature range
-60 … +100 °C
Processing temperature
-35 … +60 °C
Material data
Clamping spring material
Chrome-nickel spring steel (CrNi)
Color
orange
Contact material
Electrolytic copper (ECu)
Contact plating
Tin
Fire load
0.234 MJ
Flammability class per UL94
V0
Insulation material (main housing)
Polyamide (PA66)
Material group
I
Weight
16.7 g
Mechanical data
Anti-rotation protection
Yes
Housing sheet thickness
0.5 … 2.5 mm
Mounting type
Snap-in flange
Variable coding
Yes
Physical data
Depth
27.5 mm
Height
17.5 mm
Pin spacing
5.08 mm
Width
66.72 mm
Plug-in connection
Connector (connection type)
for conductor
Contact type (pluggable connector)
Male connector/plug
Locking of plug-in connection
Threaded flange
Mismating protection
No
Plugging without loss of pin spacing
No
