Description Potentiometric Linear Transducer MLR10
Precision miniature displacement sensor with integral return spring, 11 mm stroke length
- Linear potentiometer with almost infinite resolution
- Space-saving miniature design
- Measuring stroke 11 mm
- Double-bearing push rod
- Three electrical connection variants
- Long lifetime
The MLR10 series with integral return spring is used as a probe in applications where space is at a premium.
The miniaturized linear potentiometer is ideal for scanning measuring strokes in confined spaces. Thanks to the potentiometric conductive plastic technology, the potentiometer has a long lifespan and accuracy with almost infinite resolution. The output signal is stepless and immediately available with no computation time. The sensor principle is insensitive to EMC influences.
Three electrical connection options are available and customization of the cable (length, connector assembly) is available on request.
Main attributes Potentiometric Linear Transducer MLR10
Technical parameters
Resolution
Analogue stepless
Protection class
IP40
Effective electrical travel
11 mm
Mechanical Detection Type
Front and rear side rod with spring return
Electrical Outlet Type
Hirose plug (with 3 single strands supplied or firmly assembled)
Electr. output signal
(voltage - potentiometric)
Ind. linearity (best)
≤ ±2%
Actuating speed
< 2 m/s
Supply voltage
Potentiometric
Dimensions
Mounting
Screw Mounting / Bore Holes
Minimum overall length
Small (< 15 cm)
Temperatures
Max. operating temperature
105 °C
Min. operating temperature
-30 °C
Technology
Sensor technology
Potentiometric
